Since 1996, Precast Terrazzo Enterprises Inc., has built a magnificent portfolio of completed projects, from California to Kuwait, carving out a reputation as one of the most respected and reliable precast suppliers in the industry.



Precast Terrazzo Enterprises Inc. is 100% customizable and is furnished as a finished product that only needs to be set and leveled. Precast Terrazzo uses include but not limited to treads and risers, straight/cove base, pavers, tile, counter tops, architectural signs, ornamental elements, trash receptors, benches, etc. We offer a full suite of REVIT and CAD files to assist in your design. If you don’t see what you have in mind please contact our sales consultants to assist in your design needs.

TREAD ONLY

Full Support

(Closed Carriage)

This design features a recessed stringer to expose the edges of the treads highlighting the tread profile when viewed from the side elevation. We recommend the open carriage design be specified with finished edges, thus this design will incur a slight premium due to the extra polishing required. As with any of our full support designs this tread design can be set to steel or concrete substrates designed for a maximum deflection of L/360.

TREAD ONLY

Full Support

(Open Carriage)

This design features a recessed stringer to expose the edges of the treads highlighting the tread profile when viewed from the side elevation. We recommend the open carriage design be specified with finished edges, thus this design will incur a slight premium due to the extra polishing required. As with any of our full support designs this tread design can be set to steel or concrete substrates designed for a maximum deflection of L/360.

TREAD ONLY

Self Support

(Closed Carriage)

The beauty of a self-supporting tread is a sleek floating design with finished terrazzo on all exposed edges. These treads are engineered with steel reinforcement allowing them to span from stringer to stringer with no support. Tread thickness will vary based on the span between stringers and some designs may require the addition of a third-stringer. Please contact our sales consultants to review your specific stair design and specify the proper thickness and landing details. The extra finishing and engineering cause this stair design to be more expensive than its full support counterpart.

TREAD ONLY

Self Support

(Open Carriage)

This design takes the self-supporting tread design to a new level and provides the ultimate floating design by exposing the tread edges. These treads are engineered with steel reinforcement allowing them to span unsupported from stringer to stringer. Tread thickness will vary based on the span between stringers and some designs may require the addition of a third-stringer. Please contact our sales consultants to review your specific stair design and specify the proper thickness and landing details. The extra finishing and engineering cause this stair design to be more expensive than its full support counterpart.

TWO PIECE

TREAD & RISER

Full Support

(Closed Carriage)

The two tread and riser offer a more monolithic stair design. This is an economical and durable option great for schools. The two piece design allows for simple form work but will have a small seam at the bottom of the tread and top of the riser. As with all our tread designs they are customizable so we can produce these treads with an overhang on the tread to produce a different aesthetic. Tread thickness will vary based on the length of the tread we are producing. Full support treads are designed to be set on to a steel or concrete substrate. To accommodate dynamic loading the stair substrate must be designed for a maximum deflection of L/360. The stringer conceals the edges of the treads in this closed carriage design.

TREAD & RISER

Full Support

(Open Carriage)

This design exposes the edges of the tread riser highlighting the tread profile when view from the side elevation. We recommend the open carriage design be specified with finished edges, thus this design will incur a slight premium due to the extra polishing required. Tread thickness will vary based on the length of the tread we are producing. Full support treads are designed to be set on to a steel or concrete substrate. To accommodate dynamic loading the stair substrate must be designed for a maximum deflection of L/360.

ONE PIECE

TREAD & RISER

Full Support

(Closed Carriage)

The one piece tread and riser is a classic terrazzo stair design. This design is produced in a true “L” shaped unit which eliminates the seam between the tread and riser. Our tread designs they are customizable so we can produce the riser with a ninety-degree angle or a slight taper to produce different aesthetics. Tread thickness will vary based on the length of the tread we are producing. Full support treads are designed to be set on to a steel or concrete substrate. To accommodate dynamic loading the stair substrate must be designed for a maximum deflection of L/360. The stringer conceals the edges of the treads in this closed carriage design.

TREAD & RISER

Self Support

(Open Carriage)

This design takes the self supporting tread riser to a new level and provides the ultimate floating deign by exposing the tread edges. These treads are engineered with steel reinforcement allowing them to span unsupported from stringer to stringer. Tread thickness will vary based on the span between stringers and some designs may require the addition of a third stringer. Please contact our sales consultants to review your specific stair design and specify the proper thickness and landing details. The extra finishing and engineering cause this stair design to be more expensive than its full support counterpart.

1/3

NON SLIP

NOSING OPTIONS

These are another important component of your terrazzo stair design. The industry standard is non slip nosing using a mixture of epoxy and abrasive. These abrasive lines are embedded into the tread and sit proud of the finished surface to allow for more traction. The line thickness can be varied and the color of the epoxy can be customized.

We also offer metal inserts fabricated from zinc, stainless steel or brass. These strips are epoxied into the tread and can be provided in various gauges and spacing. The metal inserts are a premium option. Please contact our sales consultants for pricing.

Nosing Patterns

Line thickness can be varied and the color of epoxy can be customized. If you're interested in a patter that we currently don't we'd be very happy to customize it for you.

Pattern # 1 One 1/4” non-slip line

Pattern # 2 One 1/2” non-slip line

Pattern # 3 Two 1/4” non-slip lines

Pattern # 4 Two 1/2” non-slip lines

Pattern # 5 Three 1/2” non-slip lines

Pattern # 6 Three 1/4” non-slip lines

TERRAZZO

BASE

Flat Base

Terrazzo base is a great way to compliment a terrazzo floor. Flat base is an economical option that can be produce in varying heights with different top edge profiles and finishes. This base is installed after the terrazzo flooring and is typically produced in 48” pieces. We can produce curved and radius pieces for walls and columns.

Cove Base

The sanitary cove base has been commonly used with terrazzo flooring to create a seamless transition from floor to wall and eliminate the ninety degree joint that can collect dirt. This design can also be customized with different heights, cove radius and toe. We can produce with or without a divider strip on the toe of the base. The toe can also be extended further out on to the floor. The cove base is a premium base due to the radius and extra material used for the transition.

The stair landing is another important element of your stair design. We can produce stair landings in panels or tiles. We recommend panels over tile to minimize grout joints and produce a more seamless appearance. Landings are available in both full and self support and like the treads will vary in thickness based on the size of the panel. Please contact your sales consultant for your specific stair design.

Landings

OTHER

PRECAST

Terrazzo Tile

Terrazzo tile is a great option for small spaces or where you need a faster installation. Our terrazzo tiles are produced with a green guard gold resin based binder which is impervious and provides excellent stain resistance. The resinous binder also yields a very strong and durable product that is less prone to chipping or cracking and will also offer larger formats up to 4’x4’ and range in thickness from ½-¾”

Cladding, Benches and Wainscot
